MINI 300Mbps wifi signal booster/ wifi bridge/ wifi repeater

MINI 300Mbps wifi signal booster/ wifi bridge/ wifi repeater MINI 300Mbps wifi signal booster/ wifi bridge/ wifi repeater MINI 300Mbps wifi signal booster/ wifi bridge/ wifi repeater MINI 300Mbps wifi signal booster/ wifi bridge/ wifi repeater
Product name : MINI 300Mbps wifi signal booster/ wifi bridge/ wifi repeater
Item : TOP-R609
Details :
                                        MINI 300Mbps wifi signal booster/ wifi bridge/ wifi repeater

Description:

The Wireless Repeater AP extends your existing wireless network coverage with the push of a button, delivering up to 300Mbps for whole-home coverage. Ideal for hard-to-reach areas like basements, upstairs bedrooms or outdoor areas, the compact Wireless Range Extender gives you performance where you need it most

It kills Wi-Fi dead zone with strong Wi-Fi expansion at combined speed of up to 300Mbps

Features:

l  Universally complies with IEEE 802.11n, IEEE 802.11g and IEEE 802.11b standards.

l  Supports AP, and Repeater modes.

l  Provides one 10/100M LAN port

l  WLAN 802.11n for wireless high-speed access up to 300Mbps, ideal for video streaming, online gaming and Internet calling.

l  Easy Setup Assistant provides quick & hassle free installation.

l  Supports SSID broadcast control.

l  WMM and WMM-APSD supported.

l  Internal Omni Directional antenna.

l  Supports 64/128/152-bit WEP, complies with 128 bit WPA(TKIP/AES), supports MIC, IV Expansion, Shared Key Authentication, IEEE 802.1X.

l  User interface supports free WEB software updates.

l  Mini and pocket design, ideal for home or travel use.

l  300M Wireless AP with Extended Range

Specification:



Standards

 IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Wireless Signal

Rates With

Automatic Fallback

 11n: Up to 300Mbps (Dynamic)

 11g: Up to 54Mbps (Dynamic)

 11b: Up to 11Mbps (Dynamic)

Frequency Range

 2.4-2.4835GHz

Wireless

Transmit Power

 <20dBm(EIRP)

Modulation Type

 DBPSK,DQPSK,CCK, OFDM

Receiver Sensitivity

 135M: -68dBm@10% PER

 54M: -68dBm@10% PER

 11M: -85dBm@8% PER

Wireless Security

 64/128 bit WEPWPA/WPA2, WPA-PSK/WPA2-PSK

 (TKIP/AES)

Interface

 1 10/100M RJ45 Port

Power supply

 Input AC100~240V

Output DC 5V/1A

Operating Temperature

 0°C~40°C (32°F~104°F)

Storage Temperature

 -40°C~70°C (-40°F~158°F)
