Low cost RTL8188FTV mini wifi dongle 150Mbps wireless network card Realtek 8188 wifi usb adapter

Low cost RTL8188FTV mini wifi dongle 150Mbps wireless network card Realtek 8188 wifi usb adapter Low cost RTL8188FTV mini wifi dongle 150Mbps wireless network card Realtek 8188 wifi usb adapter Low cost RTL8188FTV mini wifi dongle 150Mbps wireless network card Realtek 8188 wifi usb adapter Low cost RTL8188FTV mini wifi dongle 150Mbps wireless network card Realtek 8188 wifi usb adapter
Product name : Low cost RTL8188FTV mini wifi dongle 150Mbps wireless network card Realtek 8188 wifi usb adapter
Item : TOP-7601
Details :


Low cost RTL8188FTV mini wifi dongle 150Mbps wireless network card Realtek 8188 wifi usb adapter

 TOP-1502  is a WLAN module supporting IEEE 802.11 b/g/n standards with 4-pin connector supporting USB 2.0 interface. This is a low cost compact WLAN module designed in the product with embedded system for the wireless connectivity.


TOP-1502 WLAN Module is designed to operate in 2.4GHz ISM frequency band, it applies a highly integrated MAC/BBP and RF single chip RTL8188 with 150Mbps PHY rate supporting. It fully complies with IEEE802.11n draft 3.0 and IEEE802.11b/g feature.

Specifications:

  • Supported standards and protocols: IEEE 802.11g, IEEE 802.11b, CSMA/CA with ACK, IEEE 802.11n (draft 2.0) wireless technology
  • Bus Type: USB 2.0
  • Frequency range: 2.4 to 2.4835 GHz
  • Transmission rate:11n: up to 150M/11g: 6/9/12/18/24/36/48/54Mbps (adaptive) /11b: 1/2/5.5/11M (adaptive)
  • Working channel number: 13
  • Data modulation:11b: CCK, DQPSK, DBPSK/11g:OFDM/11n: OFDM with PSK, BPSK, 16-QAM, 64-QAM
  • RF power: 20dBm (maximum)
  • Antenna gain: 2dBi built-in smart antenna
  • LED indication: Status
  • Use environment:Operating temperature: 0°C to 40°C/Storage temperature: -40°C to 70°C/Operating Humidity: 10% to 90% RH does not condense
  • Storage humidity: 5% to 90% RH does not condense
  • Support operating system: Windows 2000/XP/Vista/WIN 7.8/LINUX/MAC


  •
